9. Two PC Metal seated floating ball valve

Specification （Chemical valve）

1. Ball Valve Standard:

1. Standard compliance: API6D, API 608 ANSI B16.34 BS5351
2. Face to face: ANSI B16.10
3. RF, RTJ Flange Dimensions: ANSI B16.5 for 24"
4. Butt Weld End: ANSI B16.25
5. Pressure Rating: ANSI B16.34
6. Materials: CF8M (SS316), CF8 (SS304) CF3M (SS316L), Alloy, Hastelloy,Bronze, Titanium, Inconel, Monel etc
7. Suitable Temp.: -196ºC~550ºC
8. SuitableMedium: Water, Natural Gas, Oil, etc.


2. BallValve Features:

1. InvestmentCasting Body (2"~48")
2. Trunnion Mounted Ball Designed
3. Anti-Blow-Out stem
4. Metal to Metal Seat (Option)
5. Anti-Static Device
6. Fire Safe Designed (Option)
7. Test and Inspection: API 598 EN12266

3.   Ball Valve   Operator:

1.      Lever
2.       Worm Gear Actuator
3.       Electric, Pneumatic Actuator
4.        Hydraulic
